Strada 185 LV – Runde Einbauleuchten starr

Price range: 309,40 € through 487,90 € inkl. MwSt

SKU: Wird angezeigt, sobald alle Optionen ausgewählt sind.
Stock: Wird angezeigt, sobald alle Optionen ausgewählt sind.
For more information, please refer to the data sheet!
Bitte wählen Sie oben zunächst eine Produktvariation, um nähere Details zu erfahren.
LED-Downlight, ideal für Restaurants, Gaststätten und Wohnhäuser. Gehäuse aus Druckguss-Aluminium, mit CS Federn. Gleichmässige Ausleuchtung durch opale Abdeckung. Farbtoleranz 3 SDCM. Drahtseilabhängung l=3000 mm, transparente Zuleitung. Schutzart IP44 für geschlossene Deckensysteme. 7 Jahre Garantie
Achtung: Sie sehen aktuell nur solche technischen Daten, die für alle Variationen dieses Produkts identisch sind. Bitte wählen Sie oben eine Variation aus, um genauere Angaben zu erhalten.
Weight
1,4 kg
Dimmable

Yes, No

Operating device

LED control gear, current-controlled

Outer diameter

230 mm

Light color

white

Beam angle

41-80° – breitstrahlend

Material of the housing

Aluminum

Color

black, black/gold, black/silver, white, white/gold, white/black, white/silver

Nominal voltage

220 – 240 V

Light source

LED replaceable

Version

Without

Color rendering index CRI

80-89, 90-100

Installation height

85 mm

Adjustability

not adjustable

Voltage type

AC

Connection type

Plug-in terminal

Color temperature

3000K, 4000K

Performance

27W, 32W, 50W, 57W

Control

—, 1-10V, DALI

Variant

847-851C0365YG02, 847-851C0365YH02, 847-851C0365YJ02, 847-851C0365YK02, 847-851C0365YL02, 847-851C0365YM02, 847-851C0365YN02, SKU 847-851C0365YP02, 847-851C0365YQ02, 847-851C0365YR02, 847-851C0365YS02, 847-851C0365YT02, 847-851C0365YU02, 847-851C0365YV02, 847-851C0365YW02, 847-851C0365YX02, 847-851C0365YY02, 847-851C0365YZ02, SKU 847-851C0376YG02, 847-851C0376YH02, 847-851C0376YJ02, 847-851C0376YK02, 847-851C0376YL02, 847-851C0376YM02, 847-851C0376YN02, 847-851C0376YP02, 847-851C0376YQ02, 847-851C0376YR02, 847-851C0376YS02, 847-851C0376YT02, 847-851C0376YU02, 847-851C0376YV02, 847-851C0376YW02, 847-851C0376YX02, 847-851C0376YY02, 847-851C0376YZ02, LED Downlight 27W 3000K, LED Downlight 27W 4000K, LED Downlight 32W 3000K, LED Downlight 50W 3000K, LED Downlight 50W 4000K, LED Downlight 57W 3000K

Suitable for surface mounting
No
Suitable for recessed mounting
Yes
Suitable for wall mounting
No
Suitable for pendant suspension
No
Suitable for ceiling mounting
Yes
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
With motion detector
No
With presence detector
No
With light sensor
No
With illuminant
Yes
Suitable for number of light sources
1
Surface protection
powder-coated
Cover material
Plastic opal
Brushed surface
No
With control gear
Yes
Replaceable operating device
Yes
Dimming 0-10 V
No
DMX dimming
No
Dimming DSI
No
Dimming potentiometer (device-integrated)
No
Dimming LineSwitch
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Reflector
Without
Light distribution
symmetrical
Light emission
direct
Energy efficiency class of the light source according to EU Directive 2019/2015
not required
Ambient product after 2019/2020/EU
Yes
Rated service life L70/B50 at 25 °C
UN h
Luminous flux maintenance with average service life 50,000 h at 25 °C ambient temperature
90 %
Luminous flux maintenance with average service life 100,000 h at 25 °C ambient temperature
UN %
Failure rate at average. Service life of 35,000 h at 25 °C ambient temp. (tq)
UN %
Failure rate with average service life of 50,000 h at 25 °C ambient temperature (tq)
10 %
Failure rate with average service life of 100,000 h at 25 °C ambient temperature (tq)
UN %
Constant luminous flux control
No
Degree of protection (IP), rear
IP20
Degree of protection (IP), front
IP44
Impact resistance
IK03
Protection class according to IEC 61140
II
Rated ambient temperature according to IEC 62722-2-1
- bis - °C
Suitable for lamp wattage
NA W
Emergency power supply system
Without
Emergency function monitoring system
Without
Adjustable color temperature
No
Power factor
0,95
Adjustable beam angle
No
Installation diameter
185 mm
Type of wiring
Conclusion
Luminaire with limited surface temperature "D mark" according to EN 60598-2-24
No
Max. number of luminaires per miniature circuit breaker B16
50
Glow wire test according to IEC 60695-2-11
Without
Photobiological safety according to EN 62471
RG1
Suitable for VDU workstations according to EN 12464-1
No
Covering the luminaire with thermal insulation material possible
No
IFTTT support available
No
Color consistency (McAdam ellipse)
SDCM3
Glare limitation (UGR)
28
Compatible with Apple HomeKit
No
Operation via Bluetooth
No
Compatible with Google Assistant
No
Compatible with Casambi
No
Compatible with Amazon Alexa
No
Fire protection according to UK Building Regulations Part B - 30 minutes
No
Fire protection according to UK Building Regulations Part B - 60 minutes
No
Fire protection according to UK Building Regulations Part B - 90 minutes
No
