LED Aufbauleuchte linear, lineCENTURY 2 XS weiss 4 W 180° 4.000 K CRI80-89

Kein Preis verfügbar

SKU: AA81695.00.92
Stock: 58 Units in stock
For more information, please refer to the data sheet!
Kompakte und unauffällige LED Lichtleiste für Regale, Unterschränke, Hinterleuchtungen und Allgemeinbeleuchtung in verschiedenen Längen. Gehäuse aus Polycarbonat. Montagezubehör im Lieferumfang enthalten: 30 cm Verlängerungskabel ; 180cm Netzkabel; Befestigungshalter. Geringe Baugröße. Integriertes, nicht dimmbares Betriebsgerät. Netto 480lm. 3 Jahre Garantie.
Weight
0,09 kg
Dimensions
36,6 × 2 × 3,6 cm (L/W/H)
Color rendering index CRI

80-89

Color temperature

4.000 K

Protection class (IP)

IP44

Operating device

LED control gear, current-controlled

Voltage type

AC

Light source

LED not replaceable

Material of the housing

Plastic

Housing color

white

Nominal voltage

220 – 240 V

Beam angle

extrem breitstrahlend >80°

Light color

white

Connection type

Flat plug

Suitable for wall mounting
Yes
Suitable for pendant suspension
No
Suitable for ceiling mounting
Yes
Suitable for recessed mounting
No
Suitable for surface-mounted mounting
Yes
Suitable for strip light configuration
No
Suitable for VDU workstations according to EN 12464-1
No
With illuminant
Yes
Cover material
Plastic opal
Design of the grid
Without
With control gear
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
DALI dimming
No
DMX dimming
No
Dimming DSI
No
Dimming potentiometer (device-integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
Programmable dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Dimming depending on the control gear
Yes
Without dimming function
Yes
Light distributor
other
Light distribution
symmetrical
Light emission
direct
Energy efficiency class of the permanently installed light source
A++, A+, A (LED)
Protection class
II
Luminaire with limited surface temperature "D-mark"
No
Rated ambient temperature according to IEC62722-2-1
-20 - 25 °C
Suitable for emergency lighting
No
With motion detector
No
With light sensor
No
With air vents
No
Glow wire test according to IEC 60695-2-11
Without
Max. System performance
4 W
Luminaire luminous efficacy
120 lm/W
Type of wiring
Conclusion
Number of poles
2
AA81695.00.92.pdf
declaration_rohs_md36.pdf
