lineCENTURY 28 Multiswitch – Industrieleuchten grau 110° 4.000 K CRI80-89
77,35 € inkl. MwSt
For more information, please refer to the data sheet!Weight
5,46 kg
Dimensions
156 × 10 × 8,5 cm (L/W/H)
Connection type
Plug-in terminal
Color rendering index CRI
80-89
Color temperature
4.000 K
Voltage type
AC
Light source
LED not replaceable
Version
sonstige
Material of the housing
Plastic
Nominal voltage
220 – 240 V
Operating device
LED control gear, current-controlled
Beam angle
> 80° – extremely wide beam
Light color
white
Suitable for wall mounting
Yes
Suitable for pendant suspension
Yes
Suitable for ceiling mounting
Yes
Suitable for recessed mounting
No
Suitable for surface mounting
Yes
Suitable for strip light configuration
Yes
Suitable for clamp mounting
No
With fastening material
Yes
Suitable for VDU workstations according to EN 12464-1
No
With illuminant
Yes
Surface protection housing
untreated
Cover material
Plastic matt/satin finish
Design of the grid
Without
With control gear
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
DALI dimming
No
Dimming DALI-2
No
DMX dimming
No
Dimming DSI
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
Dimming potentiometer (device-integrated)
No
RF dimming
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Light distributor
other
Light distribution
symmetrical
Color consistency (McAdam ellipse)
SDCM3
Light emission
direct
Energy efficiency class of the light source according to EU Directive 2019/2015
not required
Ambient product after 2019/2020/EU
Yes
Rated service life L70/B50 at 25 °C
UN h
Luminous flux maintenance at average. Service life 35,000 h at 25 °C ambient temp.
UN %
Luminous flux maintenance with average service life 50,000 h at 25 °C ambient temperature
UN %
Luminous flux maintenance with average service life 75,000 h at 25 °C ambient temperature.
80 %
Failure rate at average. Service life of 35,000 h at 25 °C ambient temp. (tq)
UN %
Failure rate with average service life of 50,000 h at 25 °C ambient temperature (tq)
UN %
Failure rate with average service life of 75,000 h at 25 °C ambient temperature (tq)
20 %
Degree of protection (IP), front
IP66
Max. number of luminaires per miniature circuit breaker B16
28
Max. number of luminaires per miniature circuit breaker C16
47
Impact resistance
IK09
Protection class according to IEC 61140
I
Luminaire with limited surface temperature "D mark" according to EN 60598-2-24
No
Emergency power supply system
Without
Rated ambient temperature according to IEC 62722-2-1
- bis - °C
Suitable for emergency lighting
No
Emergency function monitoring system
Without
With switch
No
With presence detector
No
With motion detector
No
With light sensor
No
Covering the luminaire with thermal insulation material possible
No
With air vents
No
Glow wire test according to IEC 60695-2-11
850 °C - 30 s
Suitable for lamp wattage
- bis - W
Luminaire luminous efficacy
130 lm/W
Max. System performance
54 W
Power factor
0,95
Constant luminous flux control
No
Type of wiring
Suitable for through-wiring
Number of poles
2
Conductor cross-section
UN mm²
Distortion factor (THD)
UN %
Photobiological safety according to EN 62471
RG0
Operation via Bluetooth
No
Compatible with Casambi
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
Ball-proof according to DIN 18032-3
No
