Cost-efficient LED tubes with extra-high luminous flux for electromagnetic ballasts (KVG/VVG) and mains voltage
5. August 2026
ledvance/asset-13097130.jpg

Cost-efficient LED tubes with extra-high luminous flux for electromagnetic ballasts (KVG/VVG) and mains voltage

Kein Preis verfügbar

Request quotation »There is currently no price information available for this item.
SKU: 02-4099854038624
For more information, please refer to the data sheet!
Cost-efficient LED tubes for electromagnetic ballasts (KVG/VVG). Product features: LED replacement for conventional T8 fluorescent lamps with G13 base in KVG luminaires or on mains voltage. Low flicker according to EU 2019/2020 (SVM ≤0.4 / PstLM ≤ 1). Tube made of glass. High luminous flux for demanding lighting tasks. Mercury-free and RoHS compliant. Homogeneous illumination. Degree of protection: IP20. Product advantages: No sagging thanks to glass tube. Energy savings of up to 50% (compared to T8 fluorescent lamps). Simple, fast and safe lamp replacement without rewiring. Full brightness without a warm-up phase, making it ideal in combination with sensors. Very high switching strength. Also suitable for operation at low temperatures. Areas of application: General lighting in ambient temperatures of -20...+45 °C. corridors, stairwells and parking garages. Industry. Warehouses. Cold and storage rooms. Household applications. Supermarkets and department stores. Technical equipment: Suitable for operation with low-loss and conventional ballasts.
Weight
0,241 kg
Dimensions
151,4 cm (L)
Color temperature

3.000 K

Color

white

Color rendering index CRI

80-89

Nominal voltage

220 V

Voltage type

AC

Housing color

white

Beam angle

190 °

Dimmable

No

Protection class (IP)

IP20

Rated current
134 mA
Power factor
0,9
Lamp wattage
29 W
Suitable for ECG
No
Suitable for magnetic ballast
Yes
Luminous flux
3.150 lm
Rated luminous flux according to IEC 62612
3.150 lm
Lamp luminous efficacy
108 lm/W
Lamp shape
Tube, double-ended
Filament lamp
No
Glass/cover version
frosted
Base
G13
Color consistency (McAdam ellipse)
SDCM6
Dimming phase cut-off
No
Phase control dimming
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
Diameter
26,8 mm
Energy efficiency class according to EU Directive 2019/2015
F
Lamp designation
T8
Distortion factor (THD)
30 %
Min. number of switching operations
200.000
Weighted energy consumption in 1,000 hours
29 kWh
Average rated service life
30.000 h
Remote control possible
No
With motion detector
No
With remote control
No
With twilight switch
No
Photobiological safety according to EN 62471
RG0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
