LED Tubes for Electronic Ballasts (ECG), Splinter Protection
5. August 2026
LED tubes for electronic ballasts (ECG), electromagnetic ballasts (KVG/VVG) and mains voltage, splinter protection
5. August 2026
ledvance/asset-13097128.jpg

LED Tubes for Electronic Ballasts (ECG), Splinter Protection

5,63 € inkl. MwSt

SKU: 02-4099854026096
For more information, please refer to the data sheet!
LED tubes for electronic ballasts (ECG), splinter protection. Product features: LED replacement for conventional T8 fluorescent lamps with G13 base in ECG luminaires. Compatible with many commercially available electronic ballasts (see also compatibility list). Low flicker according to EU 2019/2020 (SVM ≤0.4 / PstLM ≤ 1). Glass lamp tube with shatter protection for applications e.g. in the food industry. For particularly homogeneous illumination. Mercury-free and RoHS compliant. Degree of protection: IP20. Service life: up to 75,000 h. Product advantages: No sagging thanks to glass tube. Splinter protection thanks to special PET coating. Very high switching strength. Simple, fast and safe lamp replacement without rewiring. Energy savings of up to 66% (compared to T8 fluorescent lamps). Also suitable for operation at low temperatures. Areas of application: General lighting in ambient temperatures of -20...+45 °C. Lighting in industrial production. Traffic zones and corridors. Supermarkets and department stores. Industry.
Weight
0,137 kg
Dimensions
60,3 cm (L)
Color temperature

6.500 K

Color rendering index CRI

80-89

Nominal voltage

25 V

Voltage type

AC

Beam angle

190 °

Dimmable

No

Protection class (IP)

IP20

Rated current
330 mA
Power factor
0,8
Lamp wattage
7,5 W
Suitable for ECG
Yes
Suitable for magnetic ballast
No
Luminous flux
1.100 lm
Rated luminous flux according to IEC 62612
1.100 lm
Lamp luminous efficacy
146 lm/W
Lamp shape
Tube, double-ended
Filament lamp
No
Glass/cover version
frosted
Base
G13
Color consistency (McAdam ellipse)
SDCM5
Dimming phase cut-off
No
Phase control dimming
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
Diameter
27,8 mm
Energy efficiency class according to EU Directive 2019/2015
D
Lamp designation
T8
Distortion factor (THD)
15 %
Min. number of switching operations
200.000
Weighted energy consumption in 1,000 hours
8 kWh
Average rated service life
75.000 h
Remote control possible
No
With motion detector
No
With remote control
No
With twilight switch
No
Photobiological safety according to EN 62471
RG0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
