LED Tubes for Electronic Ballasts (ECG), Splinter Protection
5. August 2026
LED tubes for electronic ballasts (ECG), electromagnetic ballasts (KVG) and mains voltage, splinter protection
5. August 2026
ledvance/asset-13013760.jpg

Cost-Effective LED Tubes for Electronic Ballasts

6,46 € inkl. MwSt

SKU: 02-4058075545366
For more information, please refer to the data sheet!
Cost-effective LED tubes for electronic ballasts (ECG). Product features: T8 glass LED tube with G13 base. Compatible with many commercially available electronic ballasts (see also compatibility list). Low flicker according to EU 2019/2020. Service life: up to 30,000 h. Mercury-free and RoHS compliant. Degree of protection: IP20. Product advantages: Easy installation. Also suitable for operation at low temperatures. No sagging thanks to glass technology. Areas of application: General lighting in ambient temperatures of -20...+45 °C. corridors, stairwells and parking garages. Warehouses.
Weight
0,109 kg
Dimensions
60,3 cm (L)
Color temperature

4.000 K

Color

white

Color rendering index CRI

80-89

Nominal voltage

20 V

Voltage type

AC

Housing color

white

Beam angle

190 °

Dimmable

No

Protection class (IP)

IP20

Rated current
60 mA
Lamp wattage
8 W
Suitable for ECG
Yes
Suitable for magnetic ballast
No
Luminous flux
800 lm
Rated luminous flux according to IEC 62612
800 lm
Lamp luminous efficacy
100 lm/W
Lamp shape
Tube, double-ended
Filament lamp
No
Glass/cover version
frosted
Light color according to EN 12464-1
neutral white 3300 to 5300 K
Base
G13
Color consistency (McAdam ellipse)
SDCM5
Dimming phase cut-off
No
Phase control dimming
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
Diameter
27,8 mm
Energy efficiency class according to EU Directive 2019/2015
F
Lamp designation
T8
Distortion factor (THD)
20 %
Min. number of switching operations
200.000
Weighted energy consumption in 1,000 hours
9 kWh
Average rated service life
30.000 h
Remote control possible
No
With motion detector
No
With remote control
No
With twilight switch
No
Photobiological safety according to EN 62471
RG0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
4058075545366.pdf
4058075545366_tds_de.pdf
asset-13130337.pdf
asset-13016007.pdf
asset-13076632.pdf

Matching accessories for this product
