Highly efficient exterior wall sensor spotlights with narrow beam angle in innovative optical design

76,74 € inkl. MwSt

SKU: 02-4058075228924
For more information, please refer to the data sheet!
Highly efficient exterior wall sensor spotlights with a narrow beam angle in an innovative optical design. Product features: 4 setting options selectable (light permanently on for 6 hours, stand-by, switching on in case of movement or twilight). Adjustable lamp head. Degree of protection: IP55. Impact resistance: IK05. Protection class: II. Product advantages: Small spotlights for precise illumination. Swivelling luminaire head enables needs-based lighting. Easy and quick installation. Areas of application: Outdoor areas. Gains. Arcades.
Weight
0,415 kg
Dimensions
17,7 × 5,8 × 18,7 cm (L/W/H)
Voltage type

AC

Color temperature

4.000 K

Adjustability

Rotatable and swiveling

Light source

LED not replaceable

Version

Without

Material of the housing

Plastic

Nominal voltage

220 – 240 V

Operating device

EVG

Dimmable

No

Light color

white

Color rendering index CRI

80-89

Suitable for surface mounting
Yes
Suitable for recessed mounting
No
Suitable for wall mounting
Yes
Suitable for pendant suspension
No
Suitable for ceiling mounting
No
Suitable for truss mounting
No
Suitable for platform/floor mounting
No
Suitable for busbar mounting
No
Suitable for clamp mounting
No
Suitable for cable system
No
With motion detector
Yes
Motion Detector/Presence Detector Technology
passive infrared
With light sensor
Yes
With illuminant
Yes
Suitable for number of light sources
0
Cover material
Plastic opal
Brushed surface
No
Rated current
86 mA
With control gear
Yes
Replaceable operating device
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI-2
No
DALI dimming
No
DMX dimming
No
Dimming DSI
No
Dimming potentiometer (device-integrated)
No
Dimming LineSwitch
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
Programmable dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Reflector
Without
Light emission
direct
Energy efficiency class of the light source according to EU Directive 2019/2015
E
Ambient product after 2019/2020/EU
Yes
Distortion factor (THD)
0 %
Rated service life L70/B50 at 25 °C
30.000 h
Constant luminous flux control
No
Impact resistance
IK05
Protection class according to IEC 61140
II
Rated ambient temperature according to IEC 62722-2-1
-20 - 40 °C
Max. System performance
16 W
Adjustable color temperature
No
Rated luminous flux according to IEC 62722-2-1
1.500 lm
Adjustable luminous flux
Steps
Luminaire luminous efficacy
86 lm/W
Adjustable beam angle
No
Type of wiring
Conclusion
Luminaire with limited surface temperature "D mark" according to EN 60598-2-24
No
Max. number of luminaires per miniature circuit breaker B16
94
Max. number of luminaires per miniature circuit breaker C16
120
Photobiological safety according to EN 62471
RG1
Suitable for VDU workstations according to EN 12464-1
No
Covering the luminaire with thermal insulation material possible
No
IFTTT support available
No
Color consistency (McAdam ellipse)
SDCM6
Compatible with Apple HomeKit
No
Operation via Bluetooth
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
