  • Compact luminaire with high luminous flux for single or continuous continuous lighting applications
Compact luminaire with high luminous flux for single or continuous continuous lighting applications
5. August 2026
Under-cabinet light with tilt function
5. August 2026
ledvance/asset-55298.jpg

Compact luminaire with high luminous flux for single or continuous continuous lighting applications

23,07 € inkl. MwSt

SKU: 02-4058075106376
For more information, please refer to the data sheet!
Compact luminaire with high luminous flux for single or continuous lighting applications. Product features: Replacement for conventional T8 or T5 luminaires. Up to 10 luminaires can be connected to each other. Transparent end caps. Linear Compact Batten connectable at the beginning of the continuous rooflight with wiring on the back. Versions with luminous flux 1000... 2500 lm available. 4 different lengths available. High luminous efficiency: up to 100 lm/W. Glow wire test according to IEC 60695-2-12: 850 °C. Product advantages: Compact dimensions. Takes up little space thanks to its compact dimensions. Seamless connection option with up to 10 luminaires per continuous lighting installation. High luminous flux up to 2500 lm. Seamless connection without visible cables when combined with Linear Compact Batten. Low-flicker light thanks to special electronic ballast. Angular connection possible with enclosed cable. Flexible installation at 2 different angles thanks to 2 mounting options. Flexible application thanks to a wide range of available lengths from 600 to 1500 mm. 5-year warranty. Areas of application: Direct replacement for luminaires with fluorescent lamps. Interior applications. Corridors, entrance areas, stairwells, living rooms, basements. Accent. Public space. Cove lighting. shelves, furniture integration or substructure. Seamless light strips. Technical equipment: Equipped with power plug, cable connector and line connector for connecting other luminaires. Mounting material for wall and ceiling mounting included.
Weight
0,6 kg
Dimensions
147,3 × 2,4 × 3,6 cm (L/W/H)
Connection type

Screw terminal

Color rendering index CRI

80-89

Protection class (IP)

IP20

Operating device

EVG

Voltage type

AC

Material

Plastic

Light source

LED not replaceable

Version

Without

Housing color

white

Nominal voltage

220 – 240 V

Dimmable

No

Color temperature

4.000 K

With illuminant
Yes
Suitable for number of light sources
0
Rated current
0,12 mA
With control gear
Yes
Replaceable operating device
No
Dimming 0-10 V
No
Dimming 1-10 V
No
DALI dimming
No
Dimming DALI-2
No
DMX dimming
No
Dimming DSI
No
Dimming LineSwitch
No
Dimming Mains voltage modulation
No
Dimming manufacturer-specific
No
Dimming phase cut-off
No
Phase control dimming
No
Dimming potentiometer (device-integrated)
No
Programmable dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming with push-button
No
Dimming Zigbee
No
Light distributor
Diffuser lens/optics/panel
Energy efficiency class of the light source according to EU Directive 2019/2015
D
Ambient product after 2019/2020/EU
Yes
Rated service life L70/B50 at 25 °C
50.000 h
Constant luminous flux control
No
Protection class according to IEC 61140
II
Impact resistance
IK03
Luminaire with limited surface temperature "D mark" according to EN 60598-2-24
No
Covering the luminaire with thermal insulation material possible
No
Suitable for emergency lighting
No
With motion detector
No
With switch
No
With light sensor
No
Max. System performance
25 W
Rated luminous flux according to IEC 62722-2-1
2.500 lm
Luminaire luminous efficacy
100 lm/W
Adjustable color temperature
No
Adjustable luminous flux
No
Adjustable beam angle
No
Number of poles
3
Electrical connection with plug-in system
No
Operation via Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
