0…10 V, AstroDIM – Konstantstrom LED-Treiber

0… 10 V, AstroDIM – constant current LED drivers

Name: 0…10 V, AstroDIM – Konstantstrom LED-Treiber
SKU: 02-4052899253438
Price: 51.67 EUR
Availability: InStock

51,67 € inkl. MwSt

SKU: 02-4052899253438

For more information, please refer to the data sheet!

0… 10 V, AstroDIM – constant current LED drivers. Product features: Available with different power: 50 W, 100 W, 110 W. Input voltage: 120 W... 277 V. Available with output current range: up to 1,400 mA. Flexible current adjustment with an additional cable (LEDset2). AstroDIM for autonomous dimming with five independent levels (Astro mode). Isolated 0... 10 V interface for unidirectional telemanagement systems. Constant luminous flux tracking. Over-temperature protection via external NTC or LEDset2 interface. Product advantages: 2DIM functionality in one device (AstroDIM, 0... 10 V). High surge protection: up to 6 kV (in protection class I or II). Fast programming without mains voltage. High efficiency and reliability. Great flexibility due to wide operating temperature range of -40... 55 °C. Protection by double insulation between mains input and LED output. High IP protection (IP64). Areas of application: Street and city lighting. Industry. Suitable for luminaires of protection class I and II. Technical equipment: OT programmer hardware required for the configuration of 2DIM ECGs. Programmable using Tuner4TRONIC™ software.

Weight

0,74 kg

Dimensions

16,8 × 6,8 × 3,8 cm (L/W/H)

Dimmable

Yes

Protection class (IP)

IP64

Execution

dynamic

Suitable for outdoor use

Dimming 0-10 V

Yes

Dimming 1-10 V

Yes

DALI dimming

Dimming DALI-2

DMX dimming

Dimming DSI

Dimming LineSwitch

Dimming Mains voltage modulation

Dimming manufacturer-specific

Dimming phase cut-off

Phase control dimming

Dimming potentiometer (device-integrated)

Programmable dimming

Yes

RF dimming

Dimming Sine Wave Reduction

Dimming Touch and Dim

Dimming with push-button

Dimming Zigbee

Constant luminous flux control

Yes

Housing

Metal housing

Suitable for constant current

Yes

Suitable for constant voltage

Suitable for DC voltage (primary side)

Efficiency

90 %

Overload protection

Yes

Overtemperature protection

Yes

Ambient temperature

-40 - 55 °C

Protection class according to IEC 61140

Operating gear life

80.000 h

Operation via Bluetooth

Compatible with Apple HomeKit

Compatible with Google Assistant

Compatible with Amazon Alexa

IFTTT support available

4052899253438.pdf

4052899253438_tds_de.pdf
