stripCENTURY 10 - LED Flex Strip flexible white 72W 120° 3000K CRI80 AA80002.00.91
31. October 2024

stripCENTURY 10 - LED Flex Strip flexible white 72W 120° 2700K CRI80 AA80002.00.90

EU-Energielabel für dieses Produkt
SKU: 685-AA80002.00.90
Datasheet: Download PDF
For further information, please refer to the data sheet!
LED strips for high demands. Ideal for applications in shop, retail and residential areas. Available in White, RGB, RGB+W, TW . Connection options on both sides with tool-free connector. 5m roll, IP00. Length - 35cm. With high-quality 3M double tape. Constant voltage 24V control gear order separately. 5-year warranty.
Weight
0,15 kg
Family

stripCENTURY 10

Execution

Ribbon

Mounting type

Structure

Light source

LED not replaceable

Number of light sources per meter

60

Lamp wattage per meter

14,4 W

Luminous flux per meter

1.380 lm

Luminaire luminous efficacy

96 lm/W

Voltage type

DC

Beam angle

120 °

Operating device

LED control gear voltage-controlled

Suitable for dimmers

Yes

Replaceable operating device

Yes

Energieeffizienzklasse der Lichtquelle nach EU-Richtlinie 2019/2015

nicht erforderlich

Luminous flux maintenance with average service life 50,000 h at 25 °C ambient temperature

70 %

Failure rate with average service life of 50,000 h at 25 °C ambient temperature (tq)

0 %

Protection class (IP)

IP00

Protection class

III

Max. System performance

72 W

Light color

white

Constant luminous flux control

No

Color temperature

2.700 K

Color rendering index CRI

80-89

Adjustable color temperature

No

Adjustable luminous flux

No

Adjustable beam angle

No

Width

10 mm

Height/depth

3 mm

Length

5.000 mm

Length of the individual sections

100 mm

With end piece

No

With connection set

Yes

With protective cover

No

Self-adhesive

Yes

Type of wiring

Suitable for through-wiring

Number of poles

2

Connection type

other

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

No

Datenblatt
AA80002.00.90-1.pdfdeclaration_stripcentury_md52-137.pdfarclite_reach_selbstverpflichtungserklaerung_24-07-30_md05-6255.pdfgpsr_montageanleitung_stripcentury_23_md14-64.pdfausschreibungstext_aa80002_00_90-1.txt
