Relco S.r.l Driver Constant Voltage 100-240V, 50-60Hz, 24Vdc, 75W, IP67, DALI2 RN1475/24/DA

SKU: 66-RN1475/24/DA
Datasheet: Download PDF
For more information, please refer to the data sheet!
This powerful 75W constant voltage LED driver with an output voltage of 24V DC is ideal for operating LED strips and modules that require a stable power supply. Thanks to its IP67 rating, it is perfect for outdoor use. In addition, the DALI 2 control allows precise adjustment of the lighting.
Manufacturer

Relco S.r.l.

Execution

dynamic

Suitable for outdoor use

No

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

Yes

Dimming DSI

No

DMX dimming

No

Dimming potentiometer (device-integrated)

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

Yes

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

Yes

Without dimming function

No

Housing

Metal housing

Suitable for constant current

No

Suitable for constant voltage

Yes

Output voltage

24 V

Output current

mA

Output power

0 – 75 W

Protection class (IP)

IP67

Protection class

II

Length

131 mm

Width

67 mm

Height

33 mm

Operation via Bluetooth

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

Compatible with Casambi

No

IFTTT support available

No

Constant luminous flux control

No

Suitable for DC voltage (primary side)

No
