High-performance LED tubes for electromagnetic ballasts (KVG/WG) and mains voltage, and for applications with high ambient temperatures
20. March 2025
ledvance/asset-13187078.jpg

High-performance LED tubes for electromagnetic ballasts (KVG/WG) and mains voltage, and for applications with high ambient temperatures

SKU: 02-4099854258572
Datasheet: Download PDF
For more information, please refer to the data sheet!
High-performance LED tubes for electromagnetic ballasts (KVG/WG) and mains voltage, and for applications with high ambient temperatures. Product features: LED replacement for conventional T8 fluorescent lamps with G13 base in KVG luminaires or on mains voltage. Very wide ambient temperature range: -20...+80°C. Low flicker according to EU 2019/2020 (SVM ?0.4 / PstLM ? 1). Service life at 25 °C ambient temperature: up to 75,000 h. Service life be≥80 °C Ambient temperature: up to 17,500 h. Protection class: IP20. ENEC 10 VDE mark. Mercury-free and RoHS compliant. Product advantages: Suitable for high ambient temperatures of more than +80° C. Very high switching strength. High luminous flux for demanding lighting tasks. Simple, fast and safe lamp replacement without rewiring. Energy savings of up to 62% (compared to T8 fluorescent lamps). Full brightness without a warm-up phase, making it ideal in combination with sensors. Also suitable for operation at low temperatures. Areas of application: General lighting in ambient temperatures of -20...+80°C. Lighting in industrial production. Industry. Technical equipment: Replacement starter for LED tubes.
Weight
0,37 kg
Nominal voltage

220 V

Rated current

66 mA

Power factor

0,9

Lamp wattage

14 W

Voltage type

AC

Suitable for ECG

No

Suitable for magnetic ballast

Yes

Luminous flux

2.600 lm

Rated luminous flux according to IEC 62612

2.600 lm

Lamp luminous efficacy

185 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G13

Color

white

Color temperature

4.000 K

Housing color

white

Beam angle

120 °

Color consistency (McAdam ellipse)

SDCM5

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

Diameter

28 mm

Length

1.213 mm

Protection class (IP)

IP20

Energy efficiency class according to EU Directive 2019/2015

B

Lamp designation

T8

Min. number of switching operations

200.000

Distortion factor (THD)

14

Weighted energy consumption in 1,000 hours

14 kWh

Average rated service life

75.000 h

Remote control possible

No

With motion detector

No

With remote control

No

With twilight switch

No

Photobiological safety according to EN 62471

RG0

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes
