12 V low-voltage LED lamps with retrofit socket

EU-Energielabel für dieses Produkt
SKU: 02-4099854048470
Datasheet: Download PDF
For more information, please refer to the data sheet!
12 V low-voltage LED lamps with retrofit socket. Product features: Compatible with many commercially available electronic ballasts (see also compatibility list). LED alternative to low-voltage halogen lamps. Socket: G4, GY6.35. Product advantages: Variable use of DC and AC voltage possible. Good all-round light emission. Ideal for decorative and free-burning use. Long service life of up to 15,000 h. Four-year warranty. Areas of application: Decorative applications. For atmospheric lighting accents in living rooms and party cellars. Shops, hotels and restaurants. Outdoor use only in suitable outdoor luminaires.
Weight
0,004 kg
Minimum order quantity

20 pieces

Order step

20 pieces

Weight

0,004 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

12 V

Rated current

350 mA

Lamp wattage

2,6 W

Voltage type

AC/DC

Luminous flux

300 lm

Rated luminous flux according to IEC 62612

300 lm

Lamp luminous efficacy

115 lm/W

Color rendering index CRI

80-89

Filament lamp

No

Glass/cover version

clear

Light color according to EN 12464-1

warm white <3300 K

Base

other

Color

multicolored

Color temperature

2.700 K

Beam angle

320 °

Color consistency (McAdam ellipse)

SDCM6

Diameter

15 mm

Length

40 mm

Protection class (IP)

IP20

Lamp designation

other

Energy efficiency class

F

Min. number of switching operations

100.000

Weighted energy consumption in 1,000 hours

3 kWh

Average rated service life

15.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG1

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

No

Datenblatt
4099854048470_tds_de.pdfasset-13164717.pdf
Dimmable

No

With remote control

No

Power factor

0,5

Suitable for ECG

No

Suitable for magnetic ballast

No

Lamp shape

other

Housing color

gray

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

Energy efficiency class according to EU Directive 2019/2015

F

With motion detector

No

With twilight switch

No
