LED Tubes for Electronic Ballasts (ECG), Splinter Protection

SKU: 02-4099854025990
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED tubes for electronic ballasts (ECG), splinter protection. Product features: LED replacement for conventional T8 fluorescent lamps with G13 base in ECG luminaires. Compatible with many commercially available electronic ballasts (see also compatibility list). Low flicker according to EU 2019/2020 (SVM ≤0.4 / PstLM ≤ 1). Glass lamp tube with shatter protection for applications e.g. in the food industry. For particularly homogeneous illumination. Mercury-free and RoHS compliant. Degree of protection: IP20. Service life: up to 75,000 h. Product advantages: No sagging thanks to glass tube. Splinter protection thanks to special PET coating. Very high switching strength. Simple, fast and safe lamp replacement without rewiring. Energy savings of up to 66% (compared to T8 fluorescent lamps). Also suitable for operation at low temperatures. Areas of application: General lighting in ambient temperatures of -20...+45 °C. Lighting in industrial production. Traffic zones and corridors. Supermarkets and department stores. Industry.
Weight
0,284 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,284 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

42 – 72 V

Rated current

490 mA

Power factor

0,9

Lamp wattage

20 W

Voltage type

AC

Luminous flux

3.100 lm

Rated luminous flux according to IEC 62612

3.100 lm

Lamp luminous efficacy

155 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G13

Color temperature

4.000 K

Beam angle

190 °

Color consistency (McAdam ellipse)

SDCM5

Diameter

27,8 mm

Length

1.513 mm

Protection class (IP)

IP20

Lamp designation

T8

Energy efficiency class

D

Min. number of switching operations

200.000

Weighted energy consumption in 1,000 hours

20 kWh

Average rated service life

75.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

Yes

Datenblatt
4099854025990_tds_de.pdfasset-13139753-31.pdfasset-13149310.jpgasset-13101222-9.pdfasset-13146680_led_tube_t8_universal_t8_hf_t5_hf_gen_11_ballast_compatibility_2023-52.pdf
Dimmable

No

With remote control

No

Suitable for ECG

Yes

Suitable for magnetic ballast

No

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

Energy efficiency class according to EU Directive 2019/2015

D

With motion detector

No

With twilight switch

No
