LED Tubes for Mains Voltage

SKU: 02-4058075824072
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED tubes for mains connection. Product features: LED replacement for fluorescent lamps with G5 base on mains voltage. Glass lamp tube with shatter protection for applications e.g. in the food industry. High color consistency: ≤ 5 SDCM (threshold value unit). Service life: up to 50,000 h. Low flicker according to EU 2019/2020 (SVM ≤0.4 / PstLM ≤ 1). Degree of protection: IP20. Product advantages: No sagging thanks to glass technology. Splinter protection thanks to special PET coating. High luminous flux for demanding lighting tasks. Areas of application: General lighting in ambient temperatures of -20...+45 °C. Offices, public facilities. Supermarkets and department stores. Industry.
Weight
0,2 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,2 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

220 – 240 V

Rated current

160 mA

Lamp wattage

36 W

Voltage type

AC

Luminous flux

5.600 lm

Rated luminous flux according to IEC 62612

5.600 lm

Lamp luminous efficacy

155 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G5

Color

white

Color temperature

4.000 K

Beam angle

190 °

Color consistency (McAdam ellipse)

SDCM5

Diameter

19 mm

Length

1.463 mm

Protection class (IP)

IP20

Energy Efficiency Index (EEI)

0,9

Energy efficiency class

D

Min. number of switching operations

200.000

Weighted energy consumption in 1,000 hours

36 kWh

Average rated service life

50.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

Yes

Datenblatt
4058075824072_tds_de.pdfasset-13138972-26.pdfasset-13151449.jpgasset-13097884-26.pdf
Dimmable

No

With remote control

No

Power factor

0,9

Suitable for ECG

No

Suitable for magnetic ballast

No

Housing color

white

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

Energy efficiency class according to EU Directive 2019/2015

D

Distortion factor (THD)

20

With motion detector

No

With twilight switch

No
