LED tubes for electromagnetic ballasts (KVG/VVG) work with the connected sensors, splinter protection

SKU: 02-4058075823976
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED tubes for electromagnetic ballasts work with the Connected sensors. Product Features: Network Protocol: ZigBee 3.0 (2.4 GHz Mesh Network). LED TUBE T8 EM Connected can only be operated with the LEDVANCE Connected sensor. Product advantages: No sagging thanks to glass technology. Splinter protection thanks to special PET coating. Short payback period thanks to low energy consumption and low maintenance costs. Areas of application: General lighting in ambient temperatures of -20...+50°C. Parking garages, storage areas, production areas. Industry. Bureaus.
Weight
0,214 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,214 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

220 – 240 V

Rated current

73 mA

Power factor

0,9

Lamp wattage

16 W

Voltage type

AC

Luminous flux

2.400 lm

Rated luminous flux according to IEC 62612

2.400 lm

Lamp luminous efficacy

150 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G13

Color

white

Color temperature

4.000 K

Beam angle

190 °

Color consistency (McAdam ellipse)

SDCM5

Diameter

28 mm

Length

1.213 mm

Protection class (IP)

IP20

Energy Efficiency Index (EEI)

0,09

Lamp designation

other

Energy efficiency class

D

Min. number of switching operations

200.000

Weighted energy consumption in 1,000 hours

16 kWh

Average rated service life

50.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

Dimmable

Yes

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

Yes

Datenblatt
4058075823976_tds_de.pdfasset-13146857-5.pdfasset-13153730.jpgasset-13153723.jpgasset-13138979-5.pdf
With remote control

No

Suitable for ECG

No

Suitable for magnetic ballast

Yes

Housing color

white

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

No

Energy efficiency class according to EU Directive 2019/2015

D

With motion detector

No

With twilight switch

No
