LED replacement for flat KLLni with 4 pin. 2G10 socket for operation on KVG or mains voltage

SKU: 02-4058075822498
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED replacement for flat KLLni with 4 pin. 2G10 socket for operation on KVG or mains voltage. Product features: LED replacement for conventional compact fluorescent lamps in KVG luminaires or on mains voltage. Service life: up to 30,000 h. Single-sided 4-pin socket 2G10. Degree of protection: IP20. Mercury-free lamps. Product advantages: Easy installation. Low energy consumption. Not suitable for operation with electronic ballasts. Easy lamp replacement thanks to compact design. Operation directly at 230 V mains voltage possible. Areas of application: General lighting in ambient temperatures of -20...+45 °C. Bureaus. Corridors and corridors. Hotels, Restaurants.
Weight
0,175 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,175 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

220 – 240 V

Rated current

90 mA

Lamp wattage

20 W

Voltage type

AC

Luminous flux

2.250 lm

Rated luminous flux according to IEC 62612

2.250 lm

Lamp luminous efficacy

112 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, single-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

warm white <3300 K

Base

other

Color

white

Color temperature

3.000 K

Housing color

white

Beam angle

130 °

Color consistency (McAdam ellipse)

SDCM6

Diameter

89,5 mm

Length

221,5 mm

Protection class (IP)

IP20

Energy efficiency class

E

Min. number of switching operations

200.000

Distortion factor (THD)

30

Weighted energy consumption in 1,000 hours

20 kWh

Average rated service life

30.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

Yes

Datenblatt
4058075822498_tds_de.pdfasset-13139359-1.pdfasset-13151532.jpgasset-13151412.jpgasset-13102951-1.pdf
Dimmable

No

With remote control

No

Power factor

0,9

Suitable for ECG

No

Suitable for magnetic ballast

Yes

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

Energy efficiency class according to EU Directive 2019/2015

E

With motion detector

No

With twilight switch

No
