High-performance LED tubes for electromagnetic ballasts (KVG/VVG), splinter protection

SKU: 02-4058075794108
Datasheet: Download PDF
For more information, please refer to the data sheet!
High-performance LED tubes for electromagnetic ballasts (KVG/VVG), splinter protection. Product features: LED replacement for conventional T8 fluorescent lamps with G13 base in KVG luminaires or on mains voltage. Low flicker according to EU 2019/2020 (SVM ≤0.4 / PstLM ≤ 1). Glass lamp tube with shatter protection for applications e.g. in the food industry. VDE-certified according to IEC62776. For particularly homogeneous illumination. Service life: up to 75,000 h. Degree of protection: IP20. Mercury-free and RoHS compliant. Product advantages: No sagging thanks to glass tube. Splinter protection thanks to special PET coating. Support in the implementation of HACCP concepts from production to product presentation. Very high switching strength. High luminous flux for demanding lighting tasks. Simple, fast and safe lamp replacement without rewiring. Energy savings of up to 60 % (compared to T8 fluorescent lamps on the KVG). Full brightness without a warm-up phase, making it ideal in combination with sensors. Also suitable for operation at low temperatures. Areas of application: General lighting in ambient temperatures of -20...+50°C. Lighting in industrial production. Traffic zones and corridors. Supermarkets and department stores. Industry. Technical equipment: Suitable for operation with low-loss and conventional ballasts.
Weight
0,191 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,191 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

220 – 240 V

Rated current

70 mA

Lamp wattage

14,9 W

Voltage type

AC

Luminous flux

2.600 lm

Rated luminous flux according to IEC 62612

2.600 lm

Lamp luminous efficacy

174 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G13

Color

white

Color temperature

5.000 K

Beam angle

190 °

Color consistency (McAdam ellipse)

SDCM5

Diameter

26,7 mm

Length

1.212 mm

Protection class (IP)

IP20

Lamp designation

T8

Energy efficiency class

C

Min. number of switching operations

200.000

Weighted energy consumption in 1,000 hours

15 kWh

Average rated service life

75.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

Datenblatt
4058075794108_tds_de.pdfasset-13073287.pdfasset-13084908.jpgasset-13016009.pdfasset-13016007.pdfasset-13029908.pdf
Dimmable

No

With remote control

No

Power factor

0,9

Suitable for ECG

No

Suitable for magnetic ballast

Yes

Housing color

white

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

Energy efficiency class according to EU Directive 2019/2015

C

Distortion factor (THD)

20

With motion detector

No

With twilight switch

No
