LED Tubes T8 EXTERNAL for LED Drivers EXTERNAL
31. October 2024
LED DRIVER LED TUBE EXTERNAL DALI P -2X15-26W 220-240
31. October 2024
ledvance/asset-13071285.jpg

Constant Current LED Driver EXTERNAL for LED TUBE EXTERNAL T5/T8

SKU: 02-4058075730632
Datasheet: Download PDF
For more information, please refer to the data sheet!
Constant Current LED Driver EXT for LED TUBE EXT T5/T8 - Indoor. Product features: 1 channel DALI-2 certified LED control gear 4058075730632 SELV driver with protective extra-low voltage. More sophisticated installations with DALI lighting control. Service life: > 100,000 h (at T = 65 °C at Tc). ENEC-tested safety. Certified 2-channel DALI-2 LED driver 4058075730656. Product advantages: Compatible with LEDVANCE LED TUBE EXTERNAL. High flexibility due to adjustable output currents via dip switches. DALI 2.0 interface for use with dimmers and sensors. High-quality dimming of 1... 100 %. Push DIM application for easy control. Very high switching strength. 5-year warranty. Areas of application: Designed for the operation of LEDVANCE LEDTUBE EXT . Suitable for luminaires of protection class I. General lighting in ambient temperatures of -20...+50°C. Linear lighting solutions for offices, educational institutions, warehouse areas and retail. Industrial lighting (e.g. production plants, logistics centres, warehouses). Shops, supermarkets. Installation in emergency lighting systems in accordance with IEC 61347-2-13, Annex J.
Weight
0,225 kg
Minimum order quantity

25 pieces

Order step

25 pieces

Weight

0,225 kg

Product group

LED control gear (EC002710)

Constant luminous flux control

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Execution

dynamic

Without dimming function

No

Housing

Metal housing

Suitable for constant current

Yes

Suitable for constant voltage

No

Suitable for DC voltage (primary side)

Yes

Protection class (IP)

IP20

Protection class

I

Length

286 mm

Width

31 mm

Height

21 mm

DALI dimming

Yes

Dimming Touch and Dim

Yes

Dimming with push-button

Yes

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Rectifier (85044083)

REACH Indicator

No

Datenblatt
4058075730632_tds_de.pdfasset-13100468-1.pdfasset-13136704.jpgasset-13072799-1.pdf
Suitable for outdoor use

No

Dimming 0-10 V

No

Dimming 1-10 V

No

Dimming DSI

No

DMX dimming

No

Dimming potentiometer (device-integrated)

No

Dimming GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Zigbee

No

Operation via Bluetooth

No

Compatible with Casambi

No
