LED Tubes T5 EXTERNAL for LED Drivers EXTERNAL
31. October 2024
LED Tubes T5 EXTERNAL for LED Drivers EXTERNAL
31. October 2024
ledvance/asset-13071632.jpg

LED Tubes T5 EXTERNAL for LED Drivers EXTERNAL

SKU: 02-4058075730519
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED Tubes T5 EXTERNAL for LED Drivers EXTERNAL. Product Features: Designed to operate on LEDVANCE Driver LED TUBE EXTERNAL. Mercury-free and RoHS compliant. Product advantages: Compatible with LEDVANCE DRIVER LED TUBE DALI EXTERNAL. Splinter protection thanks to special PET coating. No sagging thanks to glass tube. Very high switching strength. Five-year warranty. Areas of application: Industrial lighting (e.g. production plants, logistics centres, warehouses). Linear lighting solutions for offices, educational institutions, warehouse areas and retail. Shops, supermarkets. Suitable for indoor SELV installations. General lighting in ambient temperatures of -20...+50°C.
Weight
0,137 kg
Minimum order quantity

25 pieces

Order step

25 pieces

Weight

0,137 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

41 V

Rated current

450 mA

Power factor

0,9

Lamp wattage

18 W

Voltage type

DC

Luminous flux

2.800 lm

Rated luminous flux according to IEC 62612

2.800 lm

Lamp luminous efficacy

155 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G5

Color

white

Color temperature

4.000 K

Beam angle

180 °

Color consistency (McAdam ellipse)

SDCM5

Diameter

17 mm

Length

1.463 mm

Protection class (IP)

IP20

Lamp designation

other

Energy efficiency class

D

Min. number of switching operations

200.000

Weighted energy consumption in 1,000 hours

18 kWh

Average rated service life

50.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

Dimmable

Yes

RoHS applicable

Excluded

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

Yes

Datenblatt
4058075730519_tds_de.pdfasset-13130334-12.pdfasset-13072597.jpgasset-13136704-2.jpgasset-13079979-12.pdf
With remote control

No

Suitable for ECG

No

Suitable for magnetic ballast

No

Housing color

white

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

No

Energy efficiency class according to EU Directive 2019/2015

D

With motion detector

No

With twilight switch

No
