LED strips with 500 lm/m for many applications

SKU: 02-4058075707818
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED strips with 500 lm/m for many applications. Product features: Flexible and divisible LED strip. Smallest divisible unit: 100 mm. Lifetime (L70/B50): up to 30,000 h at Tc max.: 75°C. Luminous flux: 500 lm/m. Colour rendering index Ra: 80. Wide range of colour temperatures: from warm white to cool daylight. Dimmable with suitable drivers, see auchwww.ledvance.de/dim). Product advantages: Great design freedom thanks to long, flexible LED light strips. Easy installation, tool-free connection. Easy to mount on many smooth surfaces thanks to self-adhesive tape. Maximum flexibility thanks to a large selection of accessories. Easy connection thanks to cables integrated on both sides. Areas of application: General indoor lighting. Decorative lighting. Private living areas. Technical equipment: joints, profiles and covers available for various mounting options. End caps must be ordered separately.
Weight
0,078 kg
Minimum order quantity

30 pieces

Order step

30 pieces

Weight

0,078 kg

Product group

Light tube/tape (EC002706)

Suitable for dimmers

No

Constant luminous flux control

Yes

Adjustable luminous flux

No

Adjustable beam angle

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Execution

Ribbon

Mounting type

Structure

Light source

LED not replaceable

Number of light sources per meter

70

Lamp wattage per meter

5 W

Luminous flux per meter

540 lm

Voltage type

DC

Lamp voltage

24 V

Beam angle

120 °

Rated service life L70/B50 at 25 °C

30.000 h

Protection class (IP)

IP00

Protection class (NEMA)

other

Max. System performance

24 W

Color temperature

3.000 K

Width

8 mm

Height/depth

1,5 mm

Length

5.000 mm

Smallest bending radius

30 mm

Length of the individual sections

100 mm

With end piece

No

With connection set

No

With protective cover

No

Self-adhesive

Yes

Type of wiring

Conclusion

Number of poles

2

Conductor cross-section

0,5 mm²

Connection type

Plug-in terminal

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode modules (LED modules) (85395100)

REACH Indicator

No

Datenblatt
4058075707818_tds_de.pdfasset-13063606-15.pdfasset-13067474.jpgasset-13074030-15.pdf
Luminaire luminous efficacy

108 lm/W

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Light color

white

Color rendering index CRI

80-89
