  • Pendant luminaires with edge feed for direct and indirect lighting, strong glare control, 1200 mm and DALI-2 IoT technology
Square recessed luminaires with IndiviLED® optics, 625 mm and DALI-2 IoT technology
31. October 2024
Pendant luminaires with edge feed for direct and indirect lighting, strong glare control, 1200 mm and DALI-2 IoT technology
31. October 2024
ledvance/asset-6522178.jpg

Pendant luminaires with edge feed for direct and indirect lighting, strong glare control, 1200 mm and DALI-2 IoT technology

SKU: 02-4058075504028
Datasheet: Download PDF
For more information, please refer to the data sheet!
Pendant luminaires with edge feed for direct and indirect lighting, strong glare control, 1200 mm and DALI-2 IoT technology. Product features: IoT-enabled luminaire with DALI-2 technology. Rectangular (1200 mm x 300 mm) stand-alone luminaires with direct (70 %) and indirect (30 %) light emission. Driver integrated into the remote driver box. UGR ≤ 19 according to EN12464-1. High luminous efficacy: up to 110 lm/W. Lifetime (L70/B50): 80,000 h (at 25 °C). Follows the uniform design language of LEDVANCE (SCALE Design). Very narrow aluminum housing. Product advantages: Suitable luminaire for VIVARES and other DALI-2 light management systems. Pendant luminaires with edge lighting for direct (70%) and indirect lighting (30%). Attractive and functional design for office applications. Good glare control (UGR ≤ 19). Very homogeneous light. Low maintenance and low operating costs. External driver for extended flexibility. Special light guidance design for low glare lighting. Easy and quick installation. Low-flicker light thanks to special electronic ballast. 5-year warranty. Applications: Efficient replacement for traditional T8 and T5 light strips. Bureaus. Meeting. Conference rooms. Reception areas, entrance areas. Technical equipment: Suspension kit included.
Weight
3,5 kg
Minimum order quantity

2 pieces

Order step

2 pieces

Weight

3,5 kg

Product group

Pendant light (EC001743)

Replaceable operating device

Yes

Dimming DALI-2

No

Constant luminous flux control

No

Adjustable color temperature

No

Adjustable luminous flux

No

Adjustable beam angle

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Light source

LED not replaceable

Suitable for number of light sources

0

Version

Without

Material of the housing

Aluminum

Housing color

white

Design of the grid

other

Voltage type

AC

Nominal voltage

220 – 240 V

Rated current

230 mA

LED rated current with constant current

230 mA

Without dimming function

No

Light distributor

Diffuser lens/optics/panel

Reflector

Without

Light distribution

symmetrical

Color consistency (McAdam ellipse)

SDCM4

Light emission

direct/indirect

Direct/indirect components separately adjustable

No

Rated service life L70/B50 at 25 °C

80.000 h

Rated service life L80/B10 at 25 °C

60.000 h

Protection class (IP)

IP20

Impact resistance

IK03

Protection class

I

Max. System performance

36 W

Rated luminous flux according to IEC 62722-2-1

3.800 lm

Luminaire luminous efficacy

105 lm/W

Color temperature

3.000 K

Color rendering index CRI

80-89

Width

300 mm

Height/depth

16 mm

Length

1.200 mm

With suspension

Yes

Type of wiring

Conclusion

Number of poles

5

Connection type

Plug-in terminal

Suitable for VDU workstations according to EN 12464-1

Yes

With illuminant

Yes

With control gear

Yes

DALI dimming

Yes

RoHS applicable

Excluded

Country of origin

China (CN)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)

REACH Indicator

Yes

Datenblatt
4058075504028_tds_de.pdfasset-11441329-1.pdfasset-10271627.jpgasset-10271797.jpgasset-11052836-1.pdfasset-13025141.jpg
Suitable for strip light configuration

No

Suitable for number of light sources

0

Dimming 0-10 V

No

Dimming 1-10 V

No

DMX dimming

No

Programmable dimming

No

Dimming DSI

No

RF dimming

No

Dimming potentiometer (device-integrated)

No

Dimming GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Suitable for emergency lighting

No

Integrated emergency power supply

No

Cover material

Plastic opal

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Max. Number of lights Circuit breaker C16

33

Luminaire with limited surface temperature "D mark" according to EN 60598-2-24

No

Light color

white

Glare limitation (UGR)

19

Power factor

0,9

Pendulum length

2.000 mm

Operation via Bluetooth

No
