Surface-mounted luminaire with high luminous efficacy up to 125 lm/W

SKU: 02-4058075479951
Datasheet: Download PDF
For more information, please refer to the data sheet!
Surface-mounted luminaire with high luminous flux. Product features: Very high luminous efficiency: up to 125 lm/W. Robust metal housing and PC diffuser. Wiring on the back of the luminaire. through-wiring possible. Product advantages: Replacement of conventional T8 luminaires with up to 7100 lm. Up to 60% energy savings (compared to luminaires using fluorescent lamps). Rugged housing with IK08. 5-year warranty. Areas of application: Direct replacement for luminaires with fluorescent lamps. Interior applications. Industrial and commercial halls. Public space. corridors, stairwells, basements. Technical equipment: Including mounting screws and dowels.
Weight
1,26 kg
Minimum order quantity

6 pieces

Order step

6 pieces

Weight

1,26 kg

Product group

Light strip (EC000109)

Replaceable operating device

No

Constant luminous flux control

No

Adjustable color temperature

No

Adjustable luminous flux

No

Adjustable beam angle

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Light source

LED not replaceable

Suitable for number of light sources

0

Version

Without

Material

Steel

Housing color

white

Voltage type

AC

Nominal voltage

220 – 240 V

LED rated current with constant current

115 mA

Operating device

EVG

Without dimming function

Yes

Light distributor

Diffuser lens/optics/panel

Rated service life L70/B50 at 25 °C

50.000 h

Rated service life L80/B10 at 25 °C

40.000 h

Protection class (IP)

IP20

Protection class

I

With switch

No

Max. System performance

25 W

Rated luminous flux according to IEC 62722-2-1

2.950 lm

Color temperature

4.000 K

Color rendering index CRI

80-89

Width

62 mm

Height/depth

74 mm

Length

1.168 mm

Type of wiring

Suitable for through-wiring

Number of poles

2

Connection type

Plug-in terminal

Electrical connection with plug-in system

No

With illuminant

Yes

With control gear

Yes

RoHS applicable

Yes

Country of origin

China (CN)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)

REACH Indicator

No

Datenblatt
4058075479951_tds_de.pdfasset-10502225.pdfasset-9891470.pdfasset-3746609.jpgasset-3746657.jpg
Suitable for number of light sources

0

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

No

DMX dimming

No

Dimming DSI

No

Dimming potentiometer (device-integrated)

No

Dimming GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Covering the luminaire with thermal insulation material possible

No

Suitable for emergency lighting

No

Integrated emergency power supply

No

With motion detector

No

Rated current

115 mA

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Luminaire with limited surface temperature "D mark" according to EN 60598-2-24

No

Luminaire luminous efficacy

120 lm/W

Power factor

0,9

Operation via Bluetooth

No
