Wall lamps, cylindrical with glass diffuser
31. October 2024
ledvance/asset-7948908.jpg

Wall lamps, cylindrical with glass diffuser

SKU: 02-4058075392625
Datasheet: Download PDF
For more information, please refer to the data sheet!
Wall lamps, cylindrical with glass diffuser. Product features: Diffuser made of frosted glass. Die-cast aluminum housing. Degree of protection: IP43. Product advantages: High flexibility in the choice of bulb thanks to the E27 socket. Suitable for smart applications thanks to compatibility with Smart+ lamps from LEDVANCE. Easy and quick installation. Areas of application: Entrance lighting. Terraces, balconies. Technical equipment: Full mounting and connection accessories included. No bulbs included.
Weight
1,2 kg
Minimum order quantity

4 pieces

Order step

4 pieces

Weight

1,2 kg

Product group

Ceiling/wall light (EC002892)

Replaceable operating device

No

Dimming DALI-2

No

Constant luminous flux control

No

Adjustable color temperature

No

Adjustable luminous flux

No

Adjustable beam angle

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Protection class (IP)

IP43

Without dimming function

Yes

Width

118 mm

Height/depth

212 mm

Length

210 mm

Suitable for number of light sources

1

Outer diameter

118 mm

Version

E27

Material of the housing

Aluminum

Voltage type

AC

Nominal voltage

220 – 240 V

Light emission

direct

Protection class

I

Rated ambient temperature according to IEC 62722-2-1

-20 – 40 °C

Type of wiring

Conclusion

Number of poles

3

Connection type

Screw terminal

Suitable for wall mounting

Yes

Suitable for surface mounting

Yes

RoHS applicable

Yes

Country of origin

China (CN)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, andere als ausschließl. mit LED, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051990)

REACH Indicator

No

Datenblatt
Suitable for pendant suspension

No

Suitable for ceiling mounting

No

Suitable for recessed mounting

No

Suitable for surface-mounted mounting

Yes

Suitable for strip light configuration

No

Suitable for VDU workstations according to EN 12464-1

No

With illuminant

No

Suitable for number of light sources

1

With control gear

No

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

No

DMX dimming

No

Dimming DSI

No

Dimming potentiometer (device-integrated)

No

Dimming GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Dimming depending on the control gear

No

Rated ambient temperature according to IEC62722-2-1

-20 – 40 °C

Suitable for emergency lighting

No

Integrated emergency power supply

No

With motion detector

No

With light sensor

No

Covering the luminaire with thermal insulation material possible

No

With air vents

No

Operation via Bluetooth

No

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Luminaire with limited surface temperature "D mark" according to EN 60598-2-24

No

Compatible with Casambi

No

Meets min. EIA service life criterion L90 (at 50,000 h at tq = 25 °C)

No
