LED strips with 600 lm/m for many applications

SKU: 02-4058075296992
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED strips with 600 lm/m for many applications. Product features: Flexible and divisible LED strip. Smallest divisible unit: 100 mm. Service life (L70/B50): up to 20,000 h at Tc max.: 65°C. Luminous flux: 600 lm/m. Color rendering index Ra: > 80. Available in color temperature: Warm white, white, daylight. Dimmable with suitable drivers, see auchwww.ledvance.de/dim). Product advantages: Great design freedom thanks to long, flexible LED light strips. Easy to mount on many smooth surfaces thanks to self-adhesive tape. Maximum flexibility thanks to a large selection of accessories. Easy connection thanks to cables integrated on both sides. Areas of application: General indoor lighting. Decorative lighting. Private living areas.
Weight
0,064 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,064 kg

Product group

Light tube/tape (EC002706)

Adjustable luminous flux

stepless

Execution

Ribbon

Mounting type

Structure

Light source

LED not replaceable

Number of light sources per meter

60

Number of light sources per foot

18

Lamp wattage per meter

5,5 W

Luminous flux per meter

580 lm

Voltage type

DC

Lamp voltage

24 V

Beam angle

115 °

Energy efficiency class of the permanently installed light source

A++, A+, A (LED)

Rated service life L70/B50 at 25 °C

20.000 h

Protection class (IP)

IP00

Protection class (NEMA)

1

Max. System performance

27 W

Color temperature

6.500 K

Width

8 mm

Height/depth

1,3 mm

Length

5.000 mm

Smallest bending radius

30 mm

Length of the individual sections

100 mm

With end piece

No

With connection set

No

With protective cover

No

Self-adhesive

Yes

Type of wiring

with through-wiring

Number of poles

2

Conductor cross-section

0,5 mm²

Connection type

Plug-in terminal

RoHS applicable

Yes

Country of origin

China (CN)

Commodity code

Light-emitting diode modules (LED modules) (85395100)

REACH Indicator

No

Datenblatt
4058075296992_tds_de.pdfasset-7821208.pdfasset-7007720.jpgasset-11463233.pdfasset-6959591.jpg
Luminaire luminous efficacy

105 lm/W

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Color rendering index CRI

80-89

IFTTT support available

No
