LED tubes for electromagnetic ballasts (KVG/VVG), splinter protection, for food presentation
31. October 2024
ledvance/asset-1726082.jpg

LED tubes for electromagnetic ballasts (KVG/VVG), splinter protection, for food presentation

SKU: 02-4058075292499
Datasheet: Download PDF
For more information, please refer to the data sheet!
LED tubes for electromagnetic ballasts (KVG/VVG), splinter protection, for food presentation. Product features: Specially adapted spectral light distribution (comparable to T8 FL NATURA 76). LED replacement for conventional T8 fluorescent lamps with G13 base in KVG luminaires or on mains voltage. Glass lamp tube with shatter protection for applications e.g. in the food industry. VDE-certified according to IEC62776. Degree of protection: IP20. Replacement for fluorescent lamps with G13 base. Mercury-free and RoHS compliant. Product advantages: Food looks particularly fresh and appetizing without being inadmissibly "embellished". Simple, fast and safe replacement of a fluorescent lamp without rewiring the KVG. Energy savings of up to 60 % (compared to T8 fluorescent lamps on the KVG). Splinter protection thanks to special PET coating. Support in the implementation of HACCP concepts from production to product presentation. No sagging thanks to glass tube. Areas of application: Food presentation in e.g. butchers, bakeries, supermarkets or meat processing plants. Suitable for ambient temperatures from -20 to +50° C. Technical equipment: Suitable for operation with low-loss and conventional ballasts.
Weight
0,213 kg
Minimum order quantity

10 pieces

Order step

10 pieces

Weight

0,213 kg

Product group

LED lamp/multi-LED (EC001959)

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Nominal voltage

220 – 240 V

Rated current

56 mA

Lamp wattage

11,6 W

Voltage type

AC

Luminous flux

1.100 lm

Rated luminous flux according to IEC 62612

1.100 lm

Lamp luminous efficacy

94 lm/W

Color rendering index CRI

80-89

Lamp shape

Tube, double-ended

Filament lamp

No

Glass/cover version

frosted

Light color according to EN 12464-1

neutral white 3300 to 5300 K

Base

G13

Color

white

Color temperature

3.300 K

Beam angle

190 °

Color consistency (McAdam ellipse)

SDCM5

Diameter

26,7 mm

Length

1.212 mm

Protection class (IP)

IP20

Energy Efficiency Index (EEI)

0,14

Lamp designation

T8

Min. number of switching operations

200.000

Weighted energy consumption in 1,000 hours

12 kWh

Average rated service life

50.000 h

Remote control possible

No

Photobiological safety according to EN 62471

RG0

RoHS applicable

Excluded

Country of origin

China (CN)

Commodity code

Light-emitting diode lamps (LED lamps) (85395200)

REACH Indicator

Yes

Datenblatt
4058075292499_tds_de.pdfasset-13015558-1.pdfasset-13077416.jpgasset-13016007-22.pdfasset-13016009-22.pdfasset-13015573-1.pdf
Dimmable

No

With remote control

No

Power factor

0,9

Suitable for ECG

No

Suitable for magnetic ballast

Yes

Housing color

white

Dimming phase cut-off

No

Phase control dimming

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming Bluetooth

No

Dimming Wi-Fi

No

Without dimming function

Yes

With motion detector

No

With twilight switch

No
