LINEAR IndiviLED® DIRECT EMERGENCY 1200 33 W 4000 K EM
31. October 2024
Surface-mounted luminaire for single or continuous rooflight applications
31. October 2024
ledvance/asset-3562052.jpg

Surface-mounted luminaire for single or continuous rooflight applications with emergency lighting function

SKU: 02-4058075109582
Datasheet: Download PDF
For more information, please refer to the data sheet!
Surface-mounted luminaire for single or continuous rooflight applications with emergency lighting function. Product features: Each LED with individual lens and reflector for UGR < 16 and homogeneous light distribution. Emergency lighting conversion kit according to IEC 60598-2-22 (driver and 3 hours battery operation for emergency light case) included. Easy maintenance thanks to the automatic self-test for emergency lighting in accordance with IEC 60598-2-22. Can be connected to a seamless continuous rooflight using a mechanical connector (for surface-mounted or suspended mounting). Versions with lengths of 1200 or 1500 mm are available. Luminous flux up to 5700 lm. Luminous efficiency: up to 125 lm/W. Initial color consistency: 3 SDCM (threshold value unit). Product advantages: Homogeneous light distribution and reduced glare thanks to the IndiviLED® optics. Emergency lighting function according to IEC 60598-2-22 with emergency lighting driver and battery. Low-flicker light thanks to special electronic ballast. Various mounting options. Up to 50% energy savings compared to T5 light strips. Other variants with DALI-ECG or through-wiring are also available. Rugged housing with IK06. Areas of application: Direct replacement for luminaires with fluorescent lamps. Offices, schools. General interior lighting. Corridors, entrance areas. Seamless light strips. Shop lighting. Technical equipment: Ceiling junction box available. Suspension set available. Mechanical connector available. Through-wiring set available.
Weight
3,1 kg
Minimum order quantity

4 pieces

Order step

4 pieces

Weight

3,1 kg

Product group

Ceiling/wall light (EC002892)

Replaceable operating device

No

Dimming DALI-2

No

Max. Number of lights Circuit breaker C16

64

Adjustable color temperature

No

Adjustable luminous flux

No

Adjustable beam angle

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

Yes

Housing color

white

Max. System performance

25 W

Color temperature

4.000 K

Protection class (IP)

IP20

Without dimming function

Yes

Width

120 mm

Height/depth

40 mm

Length

1.488 mm

Suitable for number of light sources

0

Version

other

Surface protection housing

powder-coated

Material of the housing

Aluminum

Design of the grid

dull

Voltage type

AC

Nominal voltage

220 – 240 V

Rated current

140 mA

Operating device

EVG

Light distributor

Focus lens

Color consistency (McAdam ellipse)

SDCM3

Light emission

direct

Rated service life L70/B50 at 25 °C

60.000 h

Rated service life L80/B10 at 25 °C

50.000 h

Rated service life L90/B10 at 25 °C

35.000 h

Color rendering index CRI

80-89

Impact resistance

IK06

Protection class

I

Rated ambient temperature according to IEC 62722-2-1

5 – 35 °C

Luminaire luminous efficacy

120 lm/W

Rated luminous flux according to IEC 62722-2-1

3.300 lm

Light source

LED not replaceable

Type of wiring

Suitable for through-wiring

Number of poles

2

Connection type

Screw terminal

Photobiological safety according to EN 62471

RG1

Suitable for pendant suspension

Yes

Suitable for ceiling mounting

Yes

Suitable for surface mounting

Yes

With illuminant

Yes

With control gear

Yes

Suitable for emergency lighting

Yes

Integrated emergency power supply

Yes

Suitable for VDU workstations according to EN 12464-1

Yes

RoHS applicable

Excluded

Country of origin

China (CN)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)

REACH Indicator

Yes

Datenblatt
4058075109582_tds_de.pdfasset-11439945-3.pdfasset-6723395.jpgasset-6723391.jpgasset-13053247-3.pdf
Suitable for wall mounting

No

Suitable for recessed mounting

No

Suitable for surface-mounted mounting

Yes

Suitable for strip light configuration

No

Suitable for number of light sources

0

Dimming 0-10 V

No

Dimming 1-10 V

No

DALI dimming

No

DMX dimming

No

Dimming DSI

No

Dimming potentiometer (device-integrated)

No

Dimming GPRS

No

Dimming LineSwitch

No

Dimming manufacturer-specific

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Dimming depending on the control gear

No

Rated ambient temperature according to IEC62722-2-1

5 – 35 °C

With motion detector

No

With light sensor

No

Covering the luminaire with thermal insulation material possible

No

With air vents

No

Operation via Bluetooth

No

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Luminaire with limited surface temperature "D mark" according to EN 60598-2-24

No

Light color

white

Power factor

0,9

Glare limitation (UGR)

16

Meets min. EIA service life criterion L90 (at 50,000 h at tq = 25 °C)

No
