Luminaire inserts with narrow light emission

SKU: 02-4058075102521
Datasheet: Download PDF
For more information, please refer to the data sheet!
Luminaire inserts with narrow light emission. Product features: Narrow beam angle: 25°. Luminous efficiency: up to 135 lm/W. Fixed current taps for the electrical connection. High-quality aluminum housing. Degree of protection: IP20. Follows the uniform design language of LEDVANCE (SCALE Design). Product advantages: Innovative optical design with pulled rod lens technology over the entire length of the luminaire. Internal luminaire holders secure the luminaire against falling out during installation. Simple electrical and mechanical connection to the DIN rail by means of one-click mounting. Deep-beam light distribution for use in high rooms. Clean look as mounting brackets are not visible after assembly. Plug-and-play system allows easy installation. High-quality design. Continuous rooflights with up to 81 (on-off) / 99 (DALI) luminaires and a total length of 124 m (on-off) / 151 m (DALI) possible. Energy savings of up to 65% compared to luminaires with 2 x 80W T5 lamps. Version with DALI-ECG available. Areas of application: Direct replacement for luminaires with compact fluorescent lamps. Industrial halls, high-bay warehouses, workshops, DIY stores. Discounters, supermarkets. Technical equipment: DIN rail with permanently integrated 5- (on-off) / 7-pin (DALI) wiring harness.
Weight
1,8 kg
Minimum order quantity

3 pieces

Order step

3 pieces

Weight

1,8 kg

Product group

Gear tray for continuous-row lighting system (EC000986)

Replaceable operating device

No

Adjustable beam angle

No

Adjustable color temperature

No

Adjustable luminous flux

No

Light source

LED not replaceable

Suitable for number of light sources

0

Version

Without

Material of the housing

Aluminum

Housing color

silver

Voltage type

AC/DC

Nominal voltage

220 – 240 V

Rated current

250 mA

LED rated current with constant current

250 mA

Operating device

EVG

Without dimming function

No

Light distributor

other

Reflector

Without

Light distribution

symmetrical

Light emission

direct

Color consistency (McAdam ellipse)

SDCM3

Rated service life L70/B50 at 25 °C

75.000 h

Rated service life L80/B10 at 25 °C

50.000 h

Protection class (IP)

IP20

Protection class

I

Max. System performance

53 W

Rated luminous flux according to IEC 62722-2-1

6.200 lm

Luminaire luminous efficacy

115 lm/W

Color temperature

3.000 K

Color rendering index CRI

80-89

Power factor

0,95

Width

71 mm

Height/depth

53 mm

Length

1.534 mm

Type of wiring

Suitable for through-wiring

Number of poles

5

Connection type

other

With illuminant

Yes

With control gear

Yes

DALI dimming

Yes

RoHS applicable

Yes

Country of origin

Germany (DE)

Statistische Warennummer

Lüster und andere elektrische Decken- und Wandleuchten, mit LED-Lichtquelle, aus anderen Stoffen als Kunststoff, keramischen Stoffen oder Glas (94051190)

REACH Indicator

No

Datenblatt
4058075102521_tds_de.pdfasset-11082240-6.pdfasset-3541665.jpgasset-3541766.jpgasset-13053218-6.pdf
Suitable for number of light sources

0

Dimming 0-10 V

No

Dimming 1-10 V

No

DMX dimming

No

Dimming manufacturer-specific

No

Dimming DSI

No

Dimming potentiometer (device-integrated)

No

Dimming GPRS

No

Dimming LineSwitch

No

Dimming Mains voltage modulation

No

Dimming phase cut-off

No

Phase control dimming

No

Programmable dimming

No

RF dimming

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Suitable for emergency lighting

No

Integrated emergency power supply

No

Energy efficiency class of the light source according to EU Directive 2019/2015

not required

Rated ambient temperature according to IEC 62722-2-1

-20 – 45 °C

Light color

white

Operation via Bluetooth

No

Meets min. EIA service life criterion L90 (at 50,000 h at tq = 25 °C)

No
