Wall and ceiling luminaires with high impact resistance
For more information, please refer to the data sheet!Weight
0,94 kg
Minimum order quantity
8 pieces
Order step
8 pieces
Weight
0,94 kg
Product group
Ceiling/wall light (EC002892)
Dimming DALI-2
No
Max. Number of lights Circuit breaker C16
45
Adjustable beam angle
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
Yes
Housing color
white
Max. System performance
24 W
Color temperature
3.000 K
Protection class (IP)
IP65
Without dimming function
Yes
Height/depth
61 mm
Length
300 mm
Suitable for number of light sources
0
Outer diameter
300 mm
Version
other
Surface protection housing
powder-coated
Material of the housing
Plastic
Design of the grid
dull
Voltage type
AC
Nominal voltage
220 – 240 V
Rated current
110 mA
Operating device
EVG
Light distributor
Diffuser lens/optics/panel
Color consistency (McAdam ellipse)
SDCM4
Light emission
direct
Rated service life L70/B50 at 25 °C
50.000 h
Rated service life L80/B10 at 25 °C
30.000 h
Rated service life L90/B10 at 25 °C
15.000 h
Impact resistance
IK10
Protection class
II
Rated ambient temperature according to IEC 62722-2-1
-20 – 50 °C
Luminaire luminous efficacy
75 lm/W
Rated luminous flux according to IEC 62722-2-1
1.800 lm
Light source
LED not replaceable
Power factor
0,9
Type of wiring
Suitable for through-wiring
Number of poles
2
Connection type
Plug-in terminal
Photobiological safety according to EN 62471
RG0
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for surface mounting
Yes
With illuminant
Yes
With control gear
Yes
Country of origin
China (CN)
Commodity code
Chandeliers and other electric ceiling and wall lights, with LED light source, made of plastic or ceramic materials (94051140)
REACH Indicator
No
Datenblatt
Suitable for pendant suspension
No
Suitable for recessed mounting
No
Suitable for surface-mounted mounting
Yes
Suitable for strip light configuration
No
Suitable for VDU workstations according to EN 12464-1
No
Suitable for number of light sources
0
Dimming 0-10 V
No
Dimming 1-10 V
No
DALI dimming
No
DMX dimming
No
Dimming DSI
No
Dimming potentiometer (device-integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer-specific
No
Dimming Mains voltage modulation
No
Dimming phase cut-off
No
Phase control dimming
No
RF dimming
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming depending on the control gear
No
Rated ambient temperature according to IEC62722-2-1
-20 – 50 °C
Suitable for emergency lighting
No
Integrated emergency power supply
No
With motion detector
No
With light sensor
No
Covering the luminaire with thermal insulation material possible
No
With air vents
No
Operation via Bluetooth
No
Cover material
Plastic opal
Energy efficiency class of the light source according to EU Directive 2019/2015
not required
Light color
white
Color rendering index CRI
80-89
Meets min. EIA service life criterion L90 (at 50,000 h at tq = 25 °C)
No
